Pumpe

Elektricne pumpe

Tehničke specifikacije

MONOFAZNE PUMPE
Model	Vrsta motora Snaga	Izlaz	Max kapacitet	Max visina izbačaja	Max prolaz zrna	Težina
PST2 400	Elek. motor 0,4 kW	50 mm	200 l/min	12 m	9,5 mm	11,3 kg
PS2 500	Elek. motor 0,5 kW	50 mm	220 l/min	11 m	6,0 mm	9,5 kg
PS2 800	Elek. motor 0,75 kW	50 mm	310 l/min	15 m	6,0 mm	13,2 kg
PS2 1500	Elek. motor 1,2 kW	50 mm	420 l/min	17,5 m	6,0 mm	32,5 kg
TROFAZNE PUMPE
Model	Vrsta motora Snaga	Izlaz	Max kapacitet	Max visina izbačaja	Max prolaz zrna	Težina
PS2 1503	Elek. motor 1,5 kW	50 mm	430 l/min	21,5 m	8,5 mm	29,0 kg
PS2 1503L	Elek. motor 1,5 kW	50 mm	420 l/min	20 m	8,5 mm	19,5 kg
PS3 1503	Elek. motor 1,5 kW	75 mm	670 l/min	14,4 m	8,5 mm	29,0 kg
PS2 2203	Elek. motor 2,2 kW	50 mm	500 l/min	26,0 m	8,5 mm	32,0 kg
PS2 3703	Elek. motor 3,7 kW	50 mm	450 l/min	36,5 m	8,5 mm	55,0 kg
PS3 3703	Elek. motor 3,7 kW	75 mm	900 l/min	29,0 m	8,5 mm	55,0 kg
PS4 3703	Elek. motor 3,7 kW	100 mm	1440 l/min	18,0 m	8,5 mm	55,0 kg
PS4 5503	Elek. motor 5,5 kW	100 mm	1750 l/min	22,5 m	8,5 mm	66,0 kg
PS4 7503HF	Elek. motor 7,5 kW	100 mm	2040 l/min	31,0 m	20,0 mm	93,0 kg
PS4 11003HH	Elek. motor 11,0 kW	100 mm	1440 l/min	48,5 m	8,5 mm	130,0 kg
MOTORNE PUMPE
Model	Vrsta motora Snaga	Izlaz	Max kapacitet	Max visina izbačaja	Max dubina usisa	Max prolaz zrna	Težina
PG 2A	4-T Benzinski motor 3,0 kW	50 mm	600 l/min	30 m	7,5 m	6,5 mm	24,0 kg
PG 3A	4-T Benzinski motor 4,1 kW	75 mm	1,000 l/min	30 m	7,5 m	6,5 mm	31,0 kg
PT 2A	4-T Benzinski motor 4,0 kW	50 mm	795 l/min	32 m	7,6 m	25,0 mm	43,0 kg
PT 2H	Dizel motor 3,4 kW	50 mm	795 l/min	32 m	7,6 m	25,0 mm	59,0 kg
PT 3A	4-T Benzinski motor 6,0 kW	1,515 mm	310 l/min	29 m	7,6 m	38,0 mm	64,0 kg
PT 3H	Dizel motor 5,0 kW	75 mm	1,515 l/min	29 m	7,6 m	38,0 mm	73,0 kg
